GRAFSERT Rupture Disc

A single, solid, phenolic resin-impregnated slab of graphite makes up the GRAFSERT rupture disc. This design makes the GRAFSERT a highly dependable, low-maintenance rupture disc, ideal for highly corrosive applications and remote installations.

The GRAFSERT is single-direction disc capable of withstanding burst ratios up to 80% in static service.

Varumärke: Continental Disc Corporation

Begär offert

Produktöversikt

Features

Count on the GRAFSERT for:

Flexibility of operating conditions
Corrosion resistance
Reliability, even at low pressure-ratings and smaller sizes
Extended service life
Easy installation between companion flanges

The GRAFSERT is the ideal disc to protect processing systems, truck tanks, storage tanks and closed processing vessels from damage caused by overpressure.

Every GRAFSERT disc is subjected to careful quality control. Each lot is documented from raw material to shipment, and two or more tests to destruction are performed.

To ensure maximum visibility and indication of proper installation relative to flow direction, we attach clearly visible stainless steel nameplates to each GRAFSERT disc.

Specs

Nominal Size Range: 1″ – 24″ (13 mm – 600 mm)
Burst Pressure Range: 0.25 psig – 720 psig (0,017 barg – 49,6 barg)
Maximum Recommended Operating Ratio: 80% of the rupture disc’s rated (stamped) burst pressure
Seating Configuration: Flat seat
Service: Liquid or gas
BDI Alarm System Compatible?: Yes
ASME Code Symbol Stamp Available?: Yes

Materials not indicated or shown may be available by special design.

Industry Applications

Chemical Processing
Our rupture discs are manufactured with chemical processing in mind – corrosion resistance, leak tightness, high accuracy and durability come standard.

Oil & Gas (Petrochemical)
The hydrocarbon industries require cost-effective system protection with a special focus on reducing fugitive emissions. Our catalog of configurations, materials, burst ratings and sizes make our rupture discs the right choice for these operations.

Användningsområde

Sprängbleck för kemiindustrin

Nedan presenteras sprängbleck och tillbehör som är anpassade för kemiindustrin. De ger ett snabbt och pålitligt skydd mot tryckvariationer. Detta säkerställer trygg drift, stabil processhantering och exakt trycksäkring i krävande produktionsmiljöer.

Sprängbleck för petrokemisk industri

Nedan presenteras sprängbleck och tillbehör som är anpassade för petrokemiska processer. De ger ett snabbt och tillförlitligt skydd mot tryckvariationer. På så sätt bidrar de till säker drift, stabil processkontroll och exakt trycksäkring i krävande produktionsmiljöer.
